Mitsubishi Q Series Power Supply Module Q64RP
Part number: FX3U-4DA-ADP
Availability: In stock
Contact us: inquiry@lanenelectric.com
Skicka förfrågan
Product Details of Mitsubishi Q Series Power Supply Module Q64RP
produkt introduktion
● Part No: Q64RP
● Product name: Mitsubishi Q series power supply module Q64RP
● Brand: Mitsubishi
● Place of Origin: Japan
● Warranty: 1 Year
● More details:
| Base mounting position | Duplex power supply unit mounting slot | |
| Compatible base unit | Q38RB, Q68RB, Q65WRB | |
| Input power supply voltage | AC100-120V / AC200-240V (-15 percent - plus 10 percent ) | |
| Input frequency | 50 / 60Hz ± 5 percent | |
| Input voltage distortion | Within 5 percent | |
| Input maximum apparent power | 160VA | |
| Inrush current | 20A within 8ms | |
| Rated output current | DC5V | 8.5A |
| Overcurrent protection | DC5V | 9.35A or higher |
| Overvoltage protection | DC5V | 5.5-6.5V |
| efficiency | 65 percent or more | |
| Allowable momentary power failure time | Within 20ms | |
| Withstand voltage | Between input / LG batch and output / FG batch AC2300V / 1min (elevation 0-2000m) | |
| Insulation resistance | Input / LG batch and output / FG batch, input batch and LG, output batch and FG: DC500V insulation resistance tester 10MΩ or more | |
| Operation display | LED display (normal: green, abnormal: red) | |
| fuse | Built-in (user exchange not possible) | |
| Contact output section | Use | ERR contact |
| Rated switching voltage / current | DC24V 0.5A | |
| Minimum opening / closing load | DC5V 1mA | |
| Response time | 10ms or less | |
| 12ms or less | ||
| lifespan | Over 20 million times | |
| Rated switching voltage / current load: 100,000 times or more | ||
| Surge killer | None | |
| fuse | None | |
| External wiring connection method | Screw terminal block (M3.5 screw) | |
| External dimensions | Height (H) | 98mm |
| Width (W) | 83mm | |
| Depth (D) | 115mm | |
| mass | 0.47kg | |
| Related Products |
| similar products: |
| FX3SA-10MT-CM |
| FX3SA-14MT-CM |
| FX3GA-24MR-CM |
| FX3GA-24MT-CM |
| FX3GA-40MT-CM |
| FX3GA-60MT-CM |
| FX3SA-30MR-CM |
| FX3SA-14MR-CM |
| FX3GA-40MR-CM |
| FX3SA-10MT-CM |
| FX3G-485-BD |
| FX3GA-60MR-CM |
| Payment Delivery |
● We accept TT/Western Union/ Paypal with USD OR CNY.
● We can go with both air shipping and sea shipping, door to door.
Normally, there's DHL/FedEx/UPS...
Also, you can go with your own shipping forwarder if you have one in China.
● We're doing trades under terms of EXW, shipped from Guangzhou, China.
FAQ |
1.Q: Other suppliers have a better price than yours?
A: "To create the greatest benefit for clients"is our belief, if you have a better price, please let LANEN know.We will try the best to meet your price and support you.
2.Q: What's the delivery time ?
A: For items we have in ready stock, mostly are Mitsubishi general modules, we can create the shipment immediately after payment done if it's an urgent order. For items we don't have ready storage, we can check it up together and figure out the reasonable delivery date.
3.Q: Could Lanen provide technology support?
A: Our company was established in 2002, has been in this area for more than 20 years. Our engineer team can always try the best to help you solve problems.
